AS-82F - Eigth Ant. x two Radios, HF to 6m Antenna Switch

AS-82F – Eigth Ant. x two Radios, HF to 6m Antenna Switch

Additional information

Weight	2 kg
Dimensions	28 × 40 × 10 cm

Port Isolation Graphics

Size: H= 4.5 cm ; W= 33.5 cm ; D= 18 cm
Power: 13.8 Vdc 220 mA
Maximum RF Power: 4 kW HF PEP SSB w/ SWR < 1.5:1
Operating Frequency: DC ~ 54 MHz
Switch Time: Less than 12 ms
Loss: <0.2 dB

No data was found

Category: Antenna Switches, Relay Antenna Switches

DC to 54 MHz Antenna Relay Switch

$550.00

In stock

DC to 54 MHz Two Radios Relay Switch

Choose Connector

N Connector

$0.00

N Connector

U Connector

$0.00

U Connector

In stock

Choose Switch Cable

Add to wish list

Reviews

Description

Size: H= 4.5 cm ; W= 33.5 cm ; D= 18 cm
Power: 13.8 Vdc 220 mA
Maximum RF Power: 4 kW HF PEP SSB w/ SWR < 1.5:1
Operating Frequency: DC ~ 54 MHz
Switch Time: Less than 12 ms
Loss: <0.2 dB

Additional information

Weight	2 kg
Dimensions	28 × 40 × 10 cm

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.
